Máquina cortadora láser de tubo pequeño P1260A es una máquina totalmente automática, que combina las ventajas de alta precisión y eficiencia, Y sus configuraciones de gama alta se combinan especialmente para el procesamiento de tubos de tamaño normal 10-120mm (0,4 "-4,72"). Máquina automática de corte por láser P1260A es principalmente para el grupo de clientes de tubos pequeños con gran volumen de procesamiento, puede realizar corte y procesamiento por láser de descarga, líneas de intersección, gráficos y caracteres.
La pequeña máquina cortadora láser CNC de Metal de la fábrica Golden laser le ofrece una tecnología de corte automático eficiente y precisa con el tamaño más pequeño y la mayor tasa de uso.
La huella es más pequeña, y solo un contenedor de 40HQ es suficiente para embalar, lo que puede ahorrar más costos de transporte y mejorar la utilización del espacio de fábrica.
Fácil de usar, con un solo botón. Ahorra mano de obra y haz que construyas una fábrica inteligente.
Una tecnología de procesamiento más refinada, un modo de control de soporte de tuberías más inteligente y una plataforma de nube de gestión de datos de procesamiento inteligente mejorada brindarán los mayores beneficios a los clientes.
En comparación con la máquina cortadora de tubos láser de fibra estándar, la eficiencia de procesamiento de tubos pequeños por la máquina cortadora de tubos láser de tubos pequeños puede aumentarse en un 40%.
Láser dorado ofrece una máquina de corte por láser de tubos pequeños de alta calidad, póngase en contacto con nosotros y obtenga una pequeña máquina de corte por láser de metal ¡Precio ahora!
Nombre del modelo | P1260A |
Longitud máxima de procesamiento | 6300mm (20,6') |
Rango de diámetro del tubo | Tubo redondo 10-10-1120mm (0,4 "-4,72"), tubo cuadrado 10 10 × 10-70 70 × 70mm (0,4 "-2,75") |
Peso del rodamiento de un solo tubo | 85kg (φ120mm * 5mm * 600mm) |
Fuente láser | Generador láser de fibra IPG/ nLIGHT/ Raycus |
Potencia láser | 1500W 2000W 3000W 4000W |
Repetiabilidad | 0,03mm (0.001 ") |
Velocidad de rotación | 150r/min |
Función de reconocimiento de soldadura | Opcional |
Tamaño y peso máximo del alimentador automático | 800mm × 800mm × 6500mm (2,6 × 2,6 × 21,3) ; 2T |
Dimensiones del equipo (longitud × anchura) | 12507mm × 4109mm (41 '× 13,5) |
Peso del equipo | 11 T |
Capacidad (mm) | ||||||
Material | 1500W | 2000W | 2500W | 3000W | 4000W | 6000W |
Acero al carbono | 10 | 12 | 14 | 16 | 20 | 25 |
Acero inoxidable | 6. | 8. | 10 | 10 | 12 | 12 |
Acero galvanizado | 5. | 6. | 8. | 8. | 10 | 16 |
Aluminio | 4. | 5. | 6. | 6. | 10 | 12 |
Latón | 3. | 4. | 5. | 5. | 8. | 10 |
Cobre | 2. | 2. | 3. | 3. | 4. | 6. |
Como uno de los pequeños fabricantes líderes de máquinas de corte láser de metal en China, Golden laser proporciona la mejor calidad cortadora láser pequeña de acero y pequeña máquina de corte láser de fibra a un precio competitivo. El láser dorado tiene fuertes capacidades de corte y procesamiento de metales. Y los materiales que somos expertos en el procesamiento son acero inoxidable, acero al carbono, acero galvanizado, etc. Golden Laser puede proporcionar buenos servicios de corte láser de fibra pequeña para satisfacer los requisitos de producción. |
Adecuado para tubos de tamaño normal (10 10mm-120mm), con la tasa de utilización más alta y ahorro de costes.
● Diseñado para la alimentación por lotes de tubos redondos, tubos cuadrados y tubos rectangulares.
● En comparación con el alimentador automático universal, la velocidad de alimentación es más rápida y estable, y la eficiencia aumenta un 50%.
Frente a la situación actual de difícil encontrar un contenedor y alto costo de flete, esta pequeña máquina cortadora láser de tubos solo necesita un contenedor de 40HQ para embalar, lo que ahorra mucho flete.
● Un portabrocas neumático más compacto puede evitar la deformación al sujetar tubos de diámetro pequeño.
● Control de una tecla, sujetar tubos de 10- 120mm sin cambiar las pinzas, ahorrar tiempo y aumentar la productividad.
● FUNCIÓN DE Centrado automático, velocidad de ajuste más rápida, conveniente y eficiente.
El soporte en forma de V se utiliza en una máquina cortadora de tubos por láser, y el soporte flotante axial se utiliza en unaMáquina de corte de tubos cuadrados, Que puede mejorar la precisión del procesamiento de tuberías pequeñas.
Un dispositivo de calibración automática puede garantizar la precisión de una máquina cortadora de tubos pequeños durante el corte de paredes finas y tubos de diámetro pequeño.
Una vez completado el corte por láser, los residuos y productos terminados se clasifican automáticamente sin intervención manual; El dispositivo receptor de tipo oruga es práctico y ahorra tiempo para usted.
Golden Laser offers competitive pipe laser cutting machine price for our products. They strive to provide affordable options without compromising on quality and performance.
Golden Laser offers oem tube laser services to cater to the specific needs of businesses and industries. You can directly contact us and discuss your specific project requirements to benefit from golden laser's customized and automated tube cutting services.
As one of the best fiber laser tube cutter suppliers, Golden Laser has established a strong reputation in the laser cutting industry. With years of experience and expertise, we are known for delivering high-quality products and reliable services. The company is dedicated to customer satisfaction and provides excellent professional support.
Basado en la generación anterior del sistema de corte CNC PA profesional, desarrollo y optimización en profundidad. Adopta el modo de control del bus, admite el funcionamiento de la pantalla táctil y ha diseñado una nueva interfaz de operación de la interfaz de usuario. Cuenta con 7 módulos de gestión inteligentes para la planificación, producción, proceso, depuración, diagnóstico, mantenimiento y configuración.
Alimentador automático:
Emparejar el alimentador automático completo para realizar el procesamiento automático de lotes de tubos pequeños.
Dispositivo de recepción de seguimiento:
El orugas se utiliza para recoger materiales para realizar la clasificación y almacenamiento automáticos de piezas de trabajo procesadas.
1. Todas las cortadoras de tubos láser tienen clase 3R-seguro en todas las situaciones sin protección adicional y la certificación cumple con todas las normas de la máquina.
2. 24 meses para el generador de láser IPG o n-luz; 12 meses para toda la máquina.
3. Durante el período de garantía, el Departamento postventa de Golden Laser ofrecerá servicio telefónico o en el sitio.
4. Excepto por los daños artificiales, Golden Laser ofrece los accesorios de forma gratuita durante la garantía.
4. Después del período de garantía, Golden Laser sigue ofreciendo soporte técnico preferencial.
5. Los ingenieros de Golden Laser visitarán a los clientes y proporcionarán asistencia técnica de forma regular.
6. Las oficinas de servicio posventa en Europa, América del Norte, América del Sur, Oceanía y Asia proporcionan soporte de servicio y asistencia técnica.
When you are searching for information about fiber laser pipe cutting machines, you will naturally want to know what is the laser tube cutting machine cost, why different types of laser cutting machines have different laser tube cutting machine prices, whether it is within your budget, and whether it can bring you ore benefits than input costs.
The factors that determine the Golden Laser tube laser cutting machine prices mainly include the following aspects for reference:
Brand Power
Brand is an intangible asset of an enterprise, it represents the corporate reputation and a product quality assurance of a company. Golden Laser has acquired its brand influence after wide market recognition and popular customer trust.
Configurations
Laser cutter for metal pipe has different configurations, which are divided into the high, middle, and low ends. Laser cutting metal pipe machines of the same power also have different configurations and great price differences. For example, the fiber laser or laser cutting systems, imported and domestic prices are different.
Laser Power
Fiber laser cutting machines can choose fiber laser of different power ranges. Generally speaking, the higher the power, the more expensive the price, and the correspondingly stronger laser cutting ability.
Purposes
Different industries choose different laser cutting metal tube machines, and different laser cutting pipe machines are used for different purposes. For example, in the metalworking industry, you will encounter various types of tubes with different diameters and different needs. Golden Laser will recommend that you choose a three-dimensional five-axis laser tube cutting machine with rich functions. It has powerful functions, from small pipes to large pipes, conventional pipes to special-shaped pipes, all pipe processing problems can be easily solved.
Another example is the metal furniture and fitness equipment manufacturing industries, which usually need to process metal tubes with a diameter of 10-120mm. You can choose a small tube laser cutting machine that maximizes the utilization rate and is cost-effective.
Of course, The price of the former is higher than the price of the latter of these two laser machines. If you don't know which one you should buy, contact Golden Laser right now, We will surely choose the best best metal tube laser cutting machine that suits you according to your purposes.
With more than 20 years of experience in latest laser cutting technology research and development, manufacturing, sales, and service, Golden Laser has acquired the highest laser application market share and the most important international influence in the laser cutting industry. We always adhere to the principle of "customer first". Choosing us means you can enjoy a sincere service, because we keep listening to our customers' voice, analyze their requirements, and to solve their problems with our best performance. We are able to provide excellent laser solutions, and that's why we reform the industry. Our laser tube cutter for sale complies with all machine directives and are CE/FDA/ETL certified.
The European subsidiary established by Golden Laser is being perfected and will be officially put into service in October 2022. GoldenLaser's local dealer service centers are in Korea, the United States, Russia, Ukraine, Italy, Germany, the Netherlands, Belgium, Thailand, Malaysia, Indonesia, Vietnam, South Africa, Colombia, Algeria, and other countries. That means we can give localized services and technical support for global customers. By the way, Golden Laser is looking for global fiber laser cutting machine distributors RIGHT NOW. Welcome to join us!
Yes, this small metal pipe laser cutting machine comes with Germany PA CNC laser cutting system or Cypcut system. We will recommend a suitable laser cutting system according to your production needs.
Golden Laser's laser pipe cutting machine series can be optional equipped with automatic slag removal device. At present, we provide customers with the most conventional automatic slag removal solutions in pipes, or customized solutions with grinding machines to clean the inner wall. There are also the latest water-guided slag removal solutions.
The speed of fiber laser cutting machine small P1260A can reach 150r/min and the acceleration is 1g. Its speed is always faster than other automatic fiber laser cutting pipe machine.
